3X10 Core Copper Concentric Cable

Name: 3X10 Core Copper Concentric Cable
Brand: SiTong Cable
SKU: 3X10-Core-Copper-Concentric-Cable
Availability: InStock
Rating: 4.7 (127 reviews)

Copper Concentric Cable XLPE PVC 600V

600/1000V Copper Concentric Cable, suitable for aerial, direct burial, conduit, open tray, and underground duct installation.

Implementation Standards

NTP IEC 60502-1
BS7870

Product Introduction

Application

For use in aerial, direct burial, conduit, open tray, and underground duct installation. Its maximum temperature of operation is 70℃(PVC or PE insulation) or 90℃ (XLPE insulation) and its voltage of service for all the applications is 600V.

Standard

NTP IEC 60502-1 BS7870

Construction

Conductor: Copper class 2
Insulation: XLPE
Sheath: XLPE/PE/PVC

Phase Color Code

SNE: Red, Black & White
CNE: Black

Advantages

Rich supply experience with the best price.
18 month guarantee period.
Sample free available.

Technical Specifications

Cable Specifications

Cable Size	Conductor size (AAC)	Insulation thickness (XLPE)	Concentric conductor (AAAC 8000)	Outer sheath thickness (PVC)	Overall Diameter	Cable Mass
mm²	N/mm	mm	N/mm	mm	mm	kg/km
3*10/10	7/1.35	1.0	51/0.50	1.6	18.4	645

Application Fields

Aerial installation

Direct burial

Conduit

Open tray

Underground duct installation

Packaging & Shipping

All cables will be packaged in different materials based on their outer diameter and net weight, and can be customized according to requirements
